Servo Digitalt Mini 9.5kg/0.085sek (7.4V) OMG Högvolt Programmerbart

Servo Digitalt Mini 7.1kg/0.085sek (7.4V) OMG Högvolt
Programmerbart

Levereras med plast servoarmar

Item No. OMG-MI-08CM

Operating voltage:4.8-8.4V

Operating speed:

7.4V-0.085sec/60°

8.4V-0.075sec/60°

Stall torque:

7.4V-9.5kgf.cm

8.4V-10.0kgf.cm

Gear Material:Alum.Titanium

Horn gear spline:25T Φ5.9

Size:35.8x15.2x29.5mm

Case Material:Top & bottom cover in plastic , Middle shell in metal material

Weight:28g

Bearing:2BB

Motor type: Coreless

Operating Temperature:-15℃~+70℃

Operating travel :≈180±10°

Neutral position :1520μsec

Frequency:1520uS

Refresh Rate:333Hz

Pules width range :500-2500μsec

Dead band width:2μsec

Connector wire length:180mm

Waterproof level:Dust & Water Splash Resistacne

Programmable:No
